NB-Designer V1.6.1 is the dedicated configuration software for the Omron NB-Series Human Machine Interface (HMI). This version provides a robust and stable environment for designing intuitive operator interfaces, ranging from simple machine displays to complex industrial automation systems.
1. Key Features of NB-Designer V1.6.1
-
Rich Graphic Library: Supports both Vector and Bitmap formats, ensuring sharp, professional-grade interface designs.
-
Powerful Simulation: Features high-quality Offline Simulation, allowing you to test your program logic directly on your PC without physical hardware.
-
Multi-language Support: Supports up to 32 different languages, making it ideal for international projects and global exports.
-
Advanced Data Management: Easily configure Alarms, Recipes, Data Logging, and real-time Trending charts.
-
Flexible Connectivity: Seamlessly integrates with Omron PLCs (CP1, CJ2, NX1P2…) and third-party controllers via Modbus RTU/TCP, Siemens S7-200/300/400, and Mitsubishi FX series.
2. Supported HMI Models
This version fully supports the entire NB-Series lineup:
-
NB3Q: NB3Q-TW00B, NB3Q-TW01B (3.5 inch)
-
NB5Q: NB5Q-TW00B, NB5Q-TW01B (5.6 inch)
-
NB7W: NB7W-TW00B, NB7W-TW01B (7 inch)
-
NB10W: NB10W-TW01B (10.1 inch)
3. System Requirements
-
Operating System: Windows 7, Windows 8, Windows 10 (32/64-bit), or Windows 11.
-
RAM: Minimum 512MB (2GB or more recommended).
-
Hard Disk Space: At least 1GB of free space.
-
Display Resolution: 1024 x 768 or higher.
4. Free Download Link
You can download the NB-Designer V1.6.1 software via the high-speed links below:
[Link Download NB-Designer V1.6.1 – Google Drive] (Note: If the link is broken, please leave a comment below so we can update it immediately!)
5. Quick Installation Guide
-
Download the file and extract it using WinRAR or 7-Zip.
-
Run the Setup.exe file as an Administrator.
-
Click Next and follow the on-screen instructions until the process is complete.
-
Once installed, launch the software and start your new project.
Technical Tip:
-
If your computer fails to recognize the HMI when connected via USB, navigate to the software installation folder (usually
C:\Program Files (x86)\OMRON\NB-Designer\driver) to update the driver manually.
